1. Introduction

2. Surgical Approach

a. Raise Skin Flaps in Subperichondrial Plane

b. Reposition Cartilage for Superior Helical Rim

3. Local Tissue Advancement

a. Close Skin and Bury Cartilage

b. Quilt the Cartilage to Prevent Hematoma and Cauliflower Deformity

c. Inject Local Anesthetic for Post-op Pain Control

4. Closure

Reconstruction of external ear defects often poses various challenges due to the complex anatomy of the ear and its significant role in overall facial aesthetics. The location of the defect independently impacts the repair as various locations present distinct, additional factors to consider during planning. Specifically, defects of the superior auricle complicate the reconstructive process, due to the role of the helical root and superior rim in providing mechanical support for facial accessories such as glasses or hearing aids. The approach to reconstruction must be systematic while also being individually tailored in order to appropriately restore both optimal cosmesis and function.

The featured case involves the reconstruction of a full-thickness superior helix and auricular defect in a patient who wears eyeglasses with a cochlear implant on the same side. The discussion highlights the complexity of superior auricular reconstruction as well as the various surgical options used and challenges encountered.

<h4>CHAPTER 1</h4>

<p>This is Dr. Thomas Lee.
I work at Virginia Commonwealth University
in the Department of Otolaryngology.
And the case we're gonna discuss today is a patient
who presented with basal cell carcinoma of the ear
involving the superior helix
and the upper 25% of the ear.
And this patient has significant history
of wearing cochlear implant hearing aids as well as glasses.
So, our goal of this surgery is to restore
superior helical rim so that
he can rest his glasses as well as hearing aids.
The surgical steps in this case,
we will first examine the defect when he's asleep.
And observing the defect,
we noticed that along middle anterior helix
there are signs of gross cartilage exposure.
And unfortunately as a result of that
we cannot apply skin graft.
So, the decision is then made to perform
local tissue advancement using
the skin from the concha bowl
as well as remaining triangular fossa region.
Once we had recruited sufficient skin flap,
we then positioned the cartilage
to desired location for superior helical rim.
And once the cartilage is positioned
in the desirable location,
we then close the skin so that
the entire cartilage is buried.
And the last step is to quilt the cartilage
so that we do not have hematoma and cauliflower deformity.</p>

<h4>CHAPTER 2</h4>

<p>So this gentleman had a basal cell
involving the superior helix,
just had Mohs yesterday.
The interesting about this patient
is that he has cochlear implant, so we can't use
monopolar cautery.
Let's just get the bipolar
and then we'll start buzzing all this
so that we can see
what we got going on.
Okay, suction, please.
You want a Frazier?
Oh yeah, that'd be fine.
Yeah, Frazier might be better.
Yeah.
So looking at this,
our
first priority is to
create a ledge here.
Because he wears glasses and hearing aids.
And initially, I thought we could do something more complex.
Doing helical rim advancement kind of thing,
but in this case I don't think we need to.
It's more this that I'm worried about.
But this is bare cartilage.
And I'd like to preserve this
because this is part that -
if you cut this out,
it will start sinking in.
So cosmetically,
not ideal.
Skin graft might take on that.
It might take, so we could try that.
Fitting if there's any role in
moving into the skin
to bury the cartilage,
is one thought that I have.
You have a Frazier suction?
Yep.
Can excise some of this
excess to help us fold the ear in the right position.
I tend to do something like that.
But there's excess.
Like right in the middle here.
You have a local up, please?
1% lido with epi.
Yeah.
Just gonna lift this,
drape it, maybe drape it over this.
So it looks like you're gonna have to excise some of that.
I'm not sure if it'll move that much,
but it might move
enough to provide some perichondrium.
Another option is -
can raise a skin flap here.
I do think we need to excise this portion.
What about -
this part?
If you take this out,
could that just fall in there?
It will.
But I'd prefer to preserve this rim here though.
So this is -
when you harvest ear cartilage,
you want to preserve this rim.
This ledge that sticks out of the head.
Because otherwise it will look collapsed.
So when I harvest the ear cartilage,
I kind of get it like this.
This is the ear that we get.
Can come all the way out to
PAC here and go down the scale.
So you can get an ear curl like that.
But then I always try to preserve this
to give it projection that we need.
I think this might actually move a little bit.
So you have local, please?
Yep.
I think we can lift the skin up.
Maybe on this side.
And maybe even some of this.
Local.
Do you have a marking pen?
So I think -
it's gonna be here.
So here to here.
So I want the rim to be…</p>

<h4>CHAPTER 3</h4>

<p>So what I'm doing is I'm getting -
I'm raising this perichondrium on this side,
so I'm gonna use it to cover that up, the cartilage.
I don't know what cartilage
I'm gonna sacrifice right now.
So I'm gonna
raise this
without messing with the cartilage yet.
A little bit of skin.
Excise this.
You have an elevator?
Like number nine or a freer.
I got a freer.
All right.
This part's coming up pretty easily.
I don't want to go into the rim, but
just enough to get this mobilized.
So I'm gonna leave the posterior aspect of it
attached for blood supply.
This is actually cutting.
They are, wow.
Shockingly, yes.
I can do the cartilage right there.
There we go.
Okay now, I'm gonna raise this side.
Some cuts on the cartilage.
I'm noticing.
Like right on - elevate that.
Mhm, yep.
Nice.
Mhm.
I'm thinking let's go that way, yeah?
Mhm.
It's tethered right there.
Okay.
So that's out.
A little bit, I think.
Yeah,
that looks better.
So at least we can pull this up and over.
I'm gonna elevate a little bit more here.
And the main goal is to get that cartilage covered up.
What kind of sutures do we have up?
I have...
I will use a 4-0 Vicryl first.
Okay.
But now we need to figure out how are we gonna...
I'm sorry?
The smaller of the two needles?
Just regular -
whatever needle's fine at this point.
Okay, so I'm gonna start by just tacking this.
We're gonna start wedging stuff out.
This needs to be wedged out it looks like.
So whatever I can't cover with skin,
I'm gonna wedge out.
Because it probably won't.
It'll probably get infected.
This skin I'm gonna raise.
Lift it up and over.
So the posterior aspect of the cartilage is all intact.
You want come around that bend there, Kevin?
Right there, mhm.
Yeah, see if you can lift it.
Mhm.
Yeah.
Could I have an Adson as well, please?
Yeah.
Mhm. Thank you.
Yep.
Yep.
Nice.
That's okay.
So leave that for now before I take it out
in case we need it
for the helical rim reconstruction.
We don't probably need this at this point.
Okay so,
first step is anchoring this.
Notice that...
Okay, Vicryl.</p>

<p>Do you have some sutures scissors, please?
Okay.
Okay well we'll see where we need to
cut out the
excess cartilage.
Do you have a different needle driver, please?
This is slipping.
Do you have Bovie?
Oh no, you can't use a Bovie.
15 blade, or?
I have a 15.
Yeah, 15's good.
Gonna raise this part.
There is cochlear implant stuff
around here somewhere so we need to be
mindful of how much
dissection we're doing.
Push.
Iris back.
Just gonna see if there's a way -
I don't like how this is rolling like this.
I'd like to release it back here,
to realign that.
That's better.
Skin's getting folded into it.
Mhm.
That's actually not bad.
Let's see how this looks.
I don't like that.
Let's take it out.
Mm, came through.
We can leave it.
Let's go through this.
Can I get a freer?
Gonna unroll that a little bit more.
Just roll this out.
Iris scissors.
Trying to lift the skin here so that it can be
advanced back
posteriorly.
Cover up all this cartilage, there we go.
It's released.
Can you grab that little?
So I noticed that here
is gonna be a little bit tight.
That's gonna be okay.
Right here.
There's more tethering.
It's okay.
Gonna raise this anterior skin
so that it can slide back over.
Do we have any skin hooks?
Double? Double would be nice,
yep, right there.
All right, this is redundant cartilage.
This is redundant cartilage.
15 blade.
Excise this part. We don't need this anymore.
Once again, preserving
the ledge that trajects out laterally.
Okay.
Just save that, please.
That's good.
That's good.
I think we have enough skin to close.
I'm gonna overlap this thing there.
Could we have the 15 blade back?
A fresh one.
Just gonna -
so this is, I'm noticing, rolls out too much.
I'm gonna
make it fall back.
Like kind of removing some of this, they can collapse down.
Here you go.
Knife back.
That's better.
Stack this on top of this segment.
It's cracking.
Mhm.
Looks like it's gonna close.
Stabilize up here a bit more.
This cartilage is getting -
flimsy up here.
This is clear PDS, correct?
Yes.
All right.
I don't like that too much.
Here we go.
Yep.
Okay, come on out with that for a second.
Let's see what we got going on here.
Mhm.
Do you have the iris scissors, or?
A little bit tethered right there.
That's it.
Bipolar that right there.
Mhm, just right there.
Right there, mhm.
Mhm, good.
Good, okay.</p>

<h4>CHAPTER 4</h4>

<p>Okay, do you have 4-0 chromic?
Mhm.
And then there's gonna be a ledge.
The ledge is really the key with this
functional aspect of this -
him wearing glasses
and hearing aids.
Let's see where everything lines up.
I probably have to quilt this down, too.
Do you have something on a SH needle?
Like a 2-0 or a 3-0 chromic,
on a SH. For chromic, yeah.
We got 2-0, 3-0, and 4-0.
Let me get a 3-0 on a SH. Yep.
I think skin-wise, it's gonna be okay, anteriorly.
Great.
I think I have to cut that out to roll it back.
Mhm.
It seems to be with the stump down.
If I just tack this. Yep.
I might be okay.
All right, you have a -
let me take a 4-0 Vicryl in a second, please.
I'm might just drape the perichondrium stuff down.
Just leave the skin.
Skin closure.
Just gonna spread the skin flap out first
and then we'll figure out
how to remove the skin on the backside
so that ear will fall back towards the head more.
Scissors back.
Can I see some irrigations?
Not bad.
He's bucking.
Yeah, do you have iris scissors, again?
Something needs to happen
back here -
to help it fall back.
I'm trying to set it back.
You see how it's rolling in like this?
I want it to roll back
kind of like this.
Oh.
You know what I mean?
I don't like how it's folding like this.
I want to have it fold back.
So I might have to cut...
Yeah, kind of like, I might have to
do something for it to pull back.
Mhm, he's bucking.
Again?
Yep.
It's not bad I guess.
Let's see if there's something else we can do.
You got the chromics?
Yep.
I'm gonna just quilt that one and see.
Why is it doing that?
I'm thinking in my head.
Here's the needle back. Yep.
I'm trying to think if there's a benefit in
making a cartilage cut.
Collapsed down.
I don't know.
I feel like something like this
to stabilize it more in the middle. Yeah.
It's like totally clamped, anteriorly.
True.
True.
That's actually not bad. Yeah.
I feel like, I mean, he just needs to have his ledge.
Yeah, you're right. All right, let me get a...
Like if it's pooching out,
it's fine as long as it...
Yeah, just holds everything up.
Let me get a Vicryl.
The skin is not great.
Mhm.
Mhm.
All right, it's not bad. Yep.
Do you have a 5-0 fast? Yep.
Kevin will take it, and then,
we'll close the backside.
Here you go, sir.
Mhm.
Scissors back.
Do you have one more 5-0?
- [Surgical Assistant] Oh, we need another 5-0 fast.
How about a 5-0 chromic?
Do they have a 5-0 chromic
instead of a fast?
5-0 chromic is okay?
Yeah, that's good.
Mhm.
There's skin.
Mhm.
Okay, so we're gonna close the skin here.
I'm using 5-0 chromic.
And once you get the skin closed
and the cartilage covered up,
you're gonna quilt this down
so we don't get
hematoma formation underneath it,
which would cause
cauliflower deformity.
Suction right here.
Okay, so all the cartilage is covered,
which is good.
It's kind of the hardest part
was just getting all the cartilage covered.
Where is the skin graft going?
Well we're just doing Integra.
Oh. It's Bilayer Integra.
On this guy?
Mhm.
Oh yeah, we do need a TPS drill.
And round burr for that one.
Round diamond or cutting?
Cutting, please. Okay.
Here you go.
Iris scissors.
Thank you.</p>

<p>I'm trying to see how to quilt this
so that I don't take everything apart.
Yeah.
Because his skin basically re-draped over
what we had moved things to, actually it looks pretty good.
I don't like how it's rolling but again,
our goal is to mainly just have something sit there.
Maybe,
just something like this.
And quilt this.
So I want to go along the base of this
so that it kind of
sticks down.
Quilting it to minimize hematoma formation here.
How long do you want him to wait
before he wears the implant?
Is he? Oh, like at least a week.
Okay.
Better if it's two weeks or something like that.
I wonder if she put something there.
Like a Steri's or something,
because I don't want it setting, something directly over that.
Yeah.
That's just asking for skin to open up.
Kind of want it way down there.
I think we lifted this.
Do you have a Dermabond?
Irrigation?
Let me get one more chromic, please.
Three, cutting.
Three?
Four. Four would be fine.
Four coming.
It is pretty small.
Pretty small.
You know what, let me see that chromic
one more time, please. I'm sorry.
So basically moved the skin from here
and skip our region
out laterally.
You kind of go inside the - yeah.
Do you want him to keep doing
antibiotics after?
Skin? Like to go home, yeah.
Sure. Something with skin coverage.</p>


Watch this full-length, narrated surgical video of a local tissue advancement to reconstruct a superior helical rim defect and exposed ear cartilage after Mohs surgery.

VCU Medical Center
