Bone Graft for Non-Union of Right Thumb Proximal Phalanx Fracture

Sudhir B. Rao, MD1; Mark N. Perlmutter, MS, MD, FICS, FAANOS2; Arya S. Rao3; Grant Darner4

1Big Rapids Orthopaedics
2Carolina Regional Orthopaedics
3Undergraduate Student, Deparment of Biological Sciences, Columbia University
4Duke University School of Medicine

Abstract

In this video, we describe a surgical technique for the treatment of an unstable non-union of a proximal phalangeal fracture of the thumb. The video describes the surgical exposure, preparation of the non-union site, harvesting of autogenous iliac corticocancellous bone graft, bone grafting of the defect, and stabilization with k wire fixation.

Case Overview

This video describes the surgical treatment of an established non-union of a proximal phalangeal fracture in a young teenage girl. This procedure was carried out at a mission hospital in Central America. As in many such cases, a precise history is not available, but it appears that this may have been an open fracture that became infected. This led to a non-union. At the time of presentation, the non-union was completely unstable and the distal part of the thumb was severely angulated and incapable of pinch and grasp. The flexor pollicis longus was functional but it was not clear if the long extensor tendon was intact. Because of the unstable nature of this non-union and no prospect of healing with any other form of treatment, we elected to perform a structural bone graft to facilitate union and improve stability and function in this thumb. The choice of bone graft is based on several factors. The iliac crest is a reliable source of structural graft.  This is essential to provide mechanical support to the surgical construct. Autogenous bone graft has osteogenic and osteoinductive properties that make it the best choice in a non-union situation.

The surgery is performed under general anesthesia and tourniquet control. The left upper extremity and ipsilateral iliac crest are prepped and draped in a sterile manner. The incision is made on the dorsal of the digit extending from the distal segment proximally to the metacarpal area. Deep to the subcutaneous plane, the extensor tendon was found to be scarred and deficient. The non-union site was easily identified and filled with fibrous tissue. This fibrous tissue was excised and the opposing ends of the non-union were identified. Excision of all interposed tissue, including fibrocartilaginous and fibrous tissue, must be performed meticulously to expose the healthy bleeding bone surface. Once this is achieved, the thumb is gently distracted and brought out to length. The resulting defect is now measured.

An autogenous iliac graft is harvested by making an incision over the anterior crest. The iliac apophysis is split down the middle and reflected to expose the bony iliac crest. A bicortical piece of bone is harvested, slightly larger than the measured defect. The iliac incision is repaired anatomically by approximating the split apophysis with heavy absorbable sutures and the fascia and skin in a routine manner.

The bone graft is now trimmed to size and gently impacted into position at the non-union site. The inherent stability of this construct is now obvious, but it is wise to stabilize this with a smooth K-wire. This K- wire should be drilled proximally into the head and neck of the metacarpal to provide adequate stability. The soft tissues are now repaired in an anatomic fashion. A nonadherent bulky compressive dressing is applied followed by immobilization in a plaster splint. Once the incision is healing well and the post-operative swelling stabilized a thumb spica cast is applied. This cast protects the thumb and K-wire from inadvertent mishaps and should be left in place until graft healing is evident.  The pin is easily removed at this stage. If there is any question of graft healing then the cast may be reapplied for an additional period.

In this patient due to the lack of a functioning extensor tendon, additional surgery may be necessary at a later stage to stabilize the distal joint

Discussion

This article presents the surgical management of non-union following fracture of the proximal phalangeal element in the thumb of an 11-year old child. This case was performed during a surgical mission in Honduras with the World Surgical Foundation.

Fracture of the metacarpals and phalanges is prevalent and represents approximately 40% of upper extremity fractures.1 Non-union is a complication following fracture that is defined as the absence of bone union that will not heal without further intervention. Depending on the location of the ununited fracture, the patient may present with pain, loss of function, instability, or shortening of the limb or digit. Non-union is relatively rare and occurs in less than one percent of all fractures.2 However, several factors have been implicated in the increased risk of non-unions. A few of these risk factors include the severity of trauma with soft tissue loss, inherently precarious blood supply such as in scaphoid and femoral neck fractures, infection, and inadequate stabilization. Systemic factors such as smoking and poorly controlled diabetes have been recognized as increasing the risk of non-union in otherwise uncomplicated fractures.

A non-union can be categorized as either hypertrophic or atrophic.3 Hypertrophic non-union is characterized by abundant callus formation and is due to inadequate immobilization. Treatment consists of stabilizing the fracture, usually by surgical fixation. On the other hand, atrophic non-union (as in the patient presented) is due to the failure of osteogenesis with little or no callus or bridging bone. Factors that reduce bone cell viability such as infection and loss of blood supply lead to atrophic non-unions. In children, these factors may also involve the growth plate leading to premature growth arrest. Surgical principles in the treatment of atrophic non-union include resection of unhealthy and non-viable bone and soft tissue, bone grafting to provide an osteoconductive and osteogenic environment, and internal fixation to achieve mechanical stability.

In the treatment of atrophic non-union, there are many different graft materials or graft substitutes available to fill the gap generated during debridement. Examples include autogenous bone, allograft bone, bone marrow aspirates, demineralized bone matrix, bone morphogenetic proteins, platelet-rich plasma, and ceramics.4 With regards to the optimal graft material, autogenous bone has long been recognized as the gold standard. Autogenous tissue is favorable in that it is the only graft material that provides osteogenic, osteoinductive, and osteoconductive properties.5 Other advantages of an autogenous graft are that there is no risk of eliciting an immune response, no risk of disease transmission, and generally reliable availability. The major disadvantage of autografts is that they necessitate some level of donor site morbidity and are subject to potential risks such as the injury of nerves and blood vessels, hematoma formation, infection, and persistent pain.5 Autogenous graft material harvested from many different locations has been used successfully to treat non-union following a phalangeal fracture. For structural grafts needed to bridge a gap, the iliac crest is the best source for multiple reasons.6-10 These include ease of harvest, abundant supply of corticocancellous bone, and no serious functional deficit. For phalangeal non-unions not needing a structural graft, bone from the distal radius or proximal ulna is an easier local choice. The amount of bone needed for phalangeal fracture non-unions is small, but in other situations harvesting a larger volume of iliac crest graft has led to substantial local morbidity. This has led to surgeons seeking other sources including bone graft substitutes.

In recent years, much progress has been made in novel bone graft substitutes and clinical trials reveal that bone graft substitutes can be used successfully in many situations that previously required an autogenous bone graft.11 However, these substitutes are expensive and although they may have osteoconductive and osteoinductive properties, none have the osteogenic potential of autogenous bone graft and thus it remains the gold standard in the treatment of established non-union.11

In this patient, the iliac corticocancellous bone graft functioned as a structural graft by virtue of its solid construct and stability afforded by slight overdistraction. In many diaphyseal phalangeal non-unions, this kind of construct allows immediate inherent stabilization. Supplemental fixation is usually with K-wires although small plates can be used, especially in adults where K-wire fixation is deemed unsatisfactory. Surgical stabilization allows an early range of motion. However, stability should never be compromised in favor of early mobilization in situations where the fixation is precarious as in porotic bone, in children, and uncooperative patients. In this particular case, since the patient lived in a rural area without access to frequent follow-up, we preferred to immobilize the digit until healing was complete.

Unfortunately, given the rarity of non-union following phalangeal fractures, there have been few studies that have reported outcomes following surgical management of phalangeal atrophic non-union. The most comprehensive investigations relevant to the case presented include two retrospective studies by Al-Qattan et al. In 2010, Al-Qattan reviewed the cases of four pediatric patients (mean age = 2.5 years) suffering from atrophic non-union of the proximal phalanx of the thumb.12 All patients had been previously treated with closed reduction and splinting of fractures 6–8 months before the presentation. Each patient underwent removal of dead bone, autogenous graft placement, and internal fixation with a single k-wire. The final follow-up was 1–2 years with the primary outcome measured being a range of motion of the interphalangeal (IP) joint.13 At follow-up, the average range of motion was found to be 8° with a range of 5–10°. Subsequently, a follow-up study was published, which assessed outcomes in four pediatric patients, this time with non-union of digits other than the thumb. In this study, the primary outcome was the Total Active Motion (TAM) of the operated finger compared with the TAM of the same finger on the contralateral side. The TAM of the postoperative digits was, on average, 71.5% that of the control digits. The inability to achieve a full or near-complete range of motion in these digits reflects on the complex nature of finger non-unions where the integrity of the flexor and extensor tendon units and adjacent joint contractures provide unique challenges not seen in long bone non-unions. Although union can be achieved with bone-grafting techniques, the resultant scarring of the tendons ligaments from the initial insult and subsequent surgeries often leads to permanent loss of active and passive motion.

In summary, phalangeal non-unions are rare given the frequency of fractures involving the hand.  In most cases, there are obvious causes leading to non-union. Ideally one must do everything to prevent this adverse outcome. This includes meticulous wound care and antibiotic prophylaxis in open fractures, smoking cessation, and optimal control of diabetes. In established non-unions autogenous bone grafting with internal fixation remains the gold standard of treatment.
